| Max. plate size(mm) |
100x250 |
| Max printing diameter(mm) |
Ø80 |
| Max printing length(mm) |
80 |
| Max pad head downward travel(mm) |
50 |
| Max pad head forward travel(mm) |
200 |
| Work table X-axis travel(mm) |
10 |
| Work table Y-axis travel(mm) |
80 |
| Work table Z-axis travel(mm) |
160 |
| Work table offset angle(°) |
12 |
| Pad adjustment X-axis(mm) |
45 |
| Pad adjustment Y-axis(mm) |
65 |
| Shuttle stroke(mm) |
125 |
| Conveyor pitch of index(mm) |
|
| No of jig fixture(pc) |
1 |
| Distance between work pieces(mm) |
|
| Max workpiece height(mm) |
160 |
| Pad printing pressure(MPa) |
30.1 |
| Max pad head forward pressure(MPa) |
7.5 |
| Shuttle pressure(MPa) |
4.8 |
| Conveyor pressure (MPa) |
|
| Max speed(pcs/min) |
8 |
| Air pressure(MPa/cm2) |
0.45-0.60 |
| Air consumption(L/min) |
8 |
| Power supply |
110/220V 50/60Hz |
| Power consumption(W) |
12 |
| Machine dimension(mm) |
1000X900X1460 |
| Packing dimension(mm) |
1180X1100X1700 |
| Net weight(kg) |
220 |
| Gross weight(kg) |
320 |
