IR Drying Cabinet

  Features:

  1. It is widely used for the purpose of drying, heating, dehumidifying the printed or oil-spraying products in such industries as electronic, plastic, hardware, food etc.
  2. Air in the cabinet convects up and down.
  3. Electronic auto temperature controlling system installed.
  4. Even temperature in the cabinet.
  5. High efficient heat insulation system saves the power.
  6. The good-looking appearance, stable performance, reliable and high efficient.
  7. Power supply: 380V/50Hz, 3-phase 4-wire.
  Main Specifications:

Models PM-4000KX PM-6000KX PM-8000KX
Heating power 2KW 4KW 6KW
Total power 2.5KW 4.5KW 6.5KW
Chamber size(LxWxH) 400x400x600mm 600x500x1200mm 800x500x1200mm
Dimensions 600x550x1080mm 8000x660x1780mm 1000x650x1880mm
Packing size 800x750x1280mm 950x900x1880mm 1200x850x2080mm
Weight 180kg 280kg 380kg
